BCVAN-AES-B-G24-12V-H

Name: BCVAN-AES-B-G24-12V-H
Brand: MobileBattery Vancouver
Price: 931.0 CAD
Availability: InStock

BCVAN-AES-B-G24-12V-H

$931.00 CAD

Sale Sold out

Product variants

Fast, reliable service at your convenience – book your mobile service today!

View full details

Price Includes Full Service

Your price quote includes your new battery, labour, and recycling of old battery.

LITHIUM BLUE Battery

Premium Lithium Performance
Experience the next level of reliable power with Discover® LITHIUM BLUE LiFePO4 Premium Series batteries. These units deliver long-lasting life, lightning-fast charging, and advanced BMS-controlled safety. Plus, you can easily track your battery's state of charge, voltage, current, and temperature in real-time right from your phone via Bluetooth.

Designed for Excellence
Built with intelligent engineering in mind, LITHIUM BLUE batteries feature terminal protection, field-serviceable fuses, and convenient suitcase-style carrying handles.

Hassle-Free Upgrades
These batteries are exceptionally safe, scalable for more capacity, and built to perform. Whether you are upgrading your RV or marine vehicle , our trained and fully equipped certified technicians will come to you. We make upgrading to lithium simple—just let our team do all the work.

How MobileBattery Works

We Come To You

Our expert team arrives wherever you are, handling all makes and models with ease.

The Green Team

We're committed to sustainability, recycling your old battery with the highest environmental standards.

Simplified Payment

We accept Credit (Visa, Mastercard, American Express, Discover, JCB, Union Pay), Debit, Cheque, ETF or Cash.

Battery Specifications

MECHANICAL SPECIFICATIONS

Industry Reference	BCI: Low G24R DIN:
Length A (in/mm)	10.3	262
Width B (in/mm)	6.9	175
Height C (in/mm)	8.3	210
Total Height D (in/mm)	8.3	210
Weight (lbs/kgs)	25.30	11.50
Terminal *	M8
Cell(s)	Prismatic 4S1P
Case Material
IP Rating	67
Electrolyte	LiFePO4

NOTE 1: Dimensions have a ±2 mm (0.08 in) tolerance. Weights may vary.
NOTE 2: Refer to terminal guide on website for torque values.

ELECTRICAL SPECIFICATIONS

Open Circuit Voltage (V)	12.8
Charge Voltage (Bulk Vdc)	13.8 - 14.2
Max Absorption Voltage (U1 Vdc)	13.8
Float Voltage (U2 Vdc)	13.6
BMS Max. Voltage protection (Vdc)	14.6
Suggested Low Voltage Cutoff (Vdc) *	12
BMS Min. Voltage protection (Vdc)	10.0
Max. Continuous Charge Current (I Max. Adc)	100
Min. Finishing Charge Current (I Min. Adc)	2%-3% C1 / Min. 200ma
Max Continuous Discharge Current (Adc)	100
Max Peak Current (Adc)	250
Self-Discharge (25°C / 77°F)	< 3% per month
Charge Temperature	Min: -18°C (-0°F) \| Max: 55°C (131°F)
Discharge Temperature	Min: -20°C (-4°F) \| Max: 60°C (140°F)
Storage Temperature	Min: -10°C (14°F) \| Max: 30°C (86°F)

Electrical Specifications at 25°C.
* Do not exceed maximum voltage at the battery terminals.
CAUTION: Extra considerations must be given to depths of discharge, operating voltages and currents when designing systems for use at maximum operating temperatures.

PERFORMANCE SPECIFICATIONS

Nominal Energy (kWh)		1.28
Usable DoD		100%
Rated Wh Capacity (1C)		1280
Rated Ah Capacity (1C)		100

Minutes of Discharge
@25A	@56A	@75A	@85A	@100A
240	107	80	70	60
